1. INTRODUCTION

Graph theory explores the interconnection network designs ranging from social and computer networks to molecular structures and contributes an inclusive understanding of such corresponding matters through their precise structure. The topology of any graph delivers knowledge regarding the techniques through which vertices are attached to the graph. In molecular graphs, vertices are considered to be atoms, and covalent bonds (double or triple) are taken as edges. Graph theory is an efective tool used in various research areas such as chemical graph theory (CGT), mathematical chemistry, and even coding theory [1, 2, 3]. Graph theory is the analysis of associations between various objects. Diferent graph notations are used to represent graphs, a graph is defined as a combination of a vertex and edge set \(V ( \Lambda )\) and \(E ( \Lambda )\) , respectively. There are various types of graphs, such as path, cycle, bipartite, complete, star, wheel graph, and many others. In this study, we work with simple connected graphs that are without multiple, directed, or weighted edges, and self-loops. In this paper, we are working with families of complete, star, cycle, and path graphs. A complete graph is a k-regular graph, where every vertex is connected to all other vertices. A star graph is a class of graphs in which only one vertex has degree \(n - 1\) and \(n - 1\) vertices have degree one. A cycle graph is denoted as \(C _ { n } \ ( n \geq 3 )\) and every vertex has degree 2. Path graph \(P _ { n }\) having exactly two vertices of degree one and all the others having degree 2.

Transformation graphs, akin to graph operations, help us in the development of new, complex, and important structures of our own choice. Transformation graphs hold the complete knowledge from the actual graph into a new transformed system. Therefore, if it is feasible to discover the provided graph from the transformed graph, then such a process may be utilized to figure out the structural properties of the initial graph, considering the transformation graphs for details, see [4]. In distinct mathematical literature, several graph transformations have been evaluated where the vertex set of the transformed graph is equal to \(V ( \Lambda ) \cup E ( \Lambda )\) The most prominent classification of such graphs is the total graph. The total graph \(T ( \Lambda )\) of a graph Λ is the graph whose vertex set is \(V ( \Lambda ) \cup E ( \Lambda )\) and any two vertices of \(T ( \Lambda )\) are adjacent if and only if they are either incident or adjacent in Λ [5].

A topological index (TI) transforms a molecular graph into a real number by involving diferent graph parameters like degrees, distances, and eigenvalues. Among these parameters, the connectivity or degree-related TIs are extensively investigated due to their close correlation with certain physicochemical properties of chemical species. Zagreb indices and their transformations are useful to anticipate about π-elctron energy of alternant hydrocarbons. TIs in certain combinations take part in the design of new drugs by participating in the analysis of quantitative activity and structure-property relationships. The analysis of TIs becomes very interesting for various research areas in the present era, particularly TIs impact on chemistry amongst the theoretical molecular descriptors, due to the prediction capability about physicochemical characteristics of various chemical substances. Some essential TIs of distinct networks were formerly computed in [6, 7, 8]. A chemist, Harold Wiener, initiated the idea of the pioneer distance-related index while working on boiling points of parafins and named it after his name, the Wiener index [9]. Gutman and Trinajesti´c [10, 11], were the pioneers who provided the idea of degree-related indices while studying pi-electron energy of saturated hydrocarbons, and defined as follows:

\(M_{1}(\Lambda)=\sum_{w\in V(\Lambda)}d_{\Lambda}^{2}(w)=\sum_{vw\in E(\Lambda)}[d_{\Lambda}(v)+d_{\Lambda}(w)]\)

\(M_{2}(\Lambda)=\sum_{vw\in E(\Lambda)}d_{\Lambda}(v)\cdot d_{\Lambda}(w)\)

Later on, the analysis of Zagreb indices discovered many applications in QSPR and QSAR investigations [12, 13]. Chemical applications and mathematical efects of Zagreb indices can be analyzed from [14, 15, 16]. The Zagreb indices have been manipulated to explore molecular complexity, chirality, ZE-isomorphism and hetero-systems. The specific modification of the Zagreb indices is defined with a variable parameter as, \(\alpha \in \mathbb { R }\)

\[M _ {1} ^ {(\alpha)} (\Lambda) = \sum_ {w \in V (\Lambda)} (d _ {\Lambda} (w)) ^ {\alpha}\]

\[M _ {2} ^ {(\alpha)} (\Lambda) = \sum_ {v w \in E (\Lambda)} [ d _ {\Lambda} (v) \cdot d _ {\Lambda} (w) ] ^ {\alpha}\]

These conceptions of the Zagreb indices appear to be preferably evaluated by Li et al[17, 18]. There are some unique cases α, if \(\alpha = 2\) then it is the first Zagreb index. For \(\alpha = - 1\) is the inverse degree index (IDI) described as,

\[I D I (\Lambda) = \sum_ {w \in V (\Lambda)} \frac {1}{d _ {\Lambda} (w)}\]

The name of this index was first introduced in (2005) and is also known as the modified total adjacency index [19]. For \(\alpha = { \frac { - 1 } { 2 } }\) we obtained \(( ^ { 0 } R _ { \frac { - 1 } { 2 } } ( \Lambda ) )\) zeroth-order connectivity R.I defined as,

\[{}^{0}R_{-\frac{1}{2}}(\Lambda)=\sum_{w\in V(\Lambda)}\frac{1}{\sqrt{d_{\Lambda}(w)}}\]

For \(\alpha = 3\) then,

\[F (\Lambda) = \sum_ {w \in V (\Lambda)} (d _ {\Lambda} (w)) ^ {3}\]

this topological index is called the F index or forgotten index.

The IDI initially appeared in the software Grafiti [20, 21] that generates conjectures and proved to be a promising predictor for various compounds in CGT, such as in discovering the physicochemical characteristics of various kinds of compounds like octane isomers, polychlorobiphenyls, and polyaromatic hydrocarbons [22, 23, 24]. Xu & Das [25] and Das et al. [26] sort out extremal results regarding IDI in terms of graph parameters and the relation of IDI with Randi´c and harmonic index, respectively. Based upon the idea of the semi-total line & point graphs initiated by Sampathkumar [27] along with the idea of the total graph, Wu and Meng [4] introduced the general transformation graphs \(\Lambda ^ { a b c }\), where \(a , b , c \in \{ - , + \}\). Wang et al. [28] computed the tight bounds for the general sum-connectivity index regarding transformation graphs \({ \Lambda } ^ { a b c }\). Mohanappriya et al. [29] obtained the expressions for the inverse sum and symmetric division degree indices for graph transformations \({ \Lambda } ^ { a b }\), where \(a , b \in \{ - , + \}\). Romero et al. [30] ascertained a relation between the inverse degree of a graph and other significant indices while applying them to a particular chemical structure.

Rodr´ıguez et al. [31] worked out various inequalities for IDI in terms of those indices that are useful for QSPR/QSAR analysis and also determined extremal graphs regarding IDI. Asif et al. [32] computed exact values of IDI for some unicyclic graphs and settled bounds for families for \(n\)−vertex connected graphs with the pendent path of fixed length under the efect of transformations. Manian et al. [33] introduced transformations like pendant-path, contraction to path, contraction to star, and star-translation to obtain extremal values of inverse degree and forgotten indices for a family of unicyclic graphs. Molina et al. [34] applied IDI and e^IDI to investigate the properties of octane isomers, such as acentric factor, standard enthalpy of formation, heat capacity at constant pressure, enthalpy of vaporization, entropy, and standard enthalpy of vaporization.

In [35], Molina et al. (2024) explored the IDI, deriving new inequalities, examining its extremal properties, and demonstrating its efectiveness in predicting the structural behavior of diverse molecular graph families. Similarly, in 2024, Granados et al. [36] established sharp bounds for variable topological indices, including those based on inverse degrees. They identified the graphs that achieve these bounds, strengthening the theoretical framework for molecular descriptor analysis. In 2025, Irshad et al. [37] investigated the atom–bond connectivity index under various graph transformations, highlighting how structural modifications impact the topological properties and predictive capacity of molecular graphs. In this article, we discuss various families of n-vertex networks by applying new transformations and established inequalities for IDI regarding these transformations. Also, we employ our formulas on diverse examples to check their precision and validity.

2. Motivation and Applications

The motivation for comparing transformed graphs arises from the fact that graph transformations often alter key structural properties of molecular graphs, which directly afect topological indices like the inverse degree index (IDI). By studying how IDI behaves under diferent transformations, we can learn about structural sensitivity, characterize extremal properties, develop inequalities to establish general mathematical relationships, and interpret them, which are valuable in chemical graph theory.

IDI can help predict molecular stability, reactivity, and potential reaction sites. Transformations that optimize IDI may guide the design of polymers, nanotubes, or other nanostructures with desired properties. Understanding how transformations afect IDI supports computational methods in cheminformatics. These comparison provide a theoretical aid and insight for molecular graphs akin to transformed graphs in QSPR/QSAR studies.

3. MAIN RESULTS

In this section, before addressing the main problem, we present some transformations of complete graphs attached to the graph. These transformations have solid outcomes over the increase and decrease of \(I D I ( \Lambda )\) . Throughout in this paper, assume the graph \(\Lambda _ { n , m } ^ { k , l }\) comprises on \(n\)-vertices and \(m\)-edges simple graph Λ together with k number complete graphs of order \(l , ( l \geq 3 )\) connected with \(v \in \Lambda\) of degree \(d _ { v } \geq 1 . \ n + k ( l - 1 )\) be the order of \(\Lambda _ { n , m } ^ { k , l } , \frac { 2 \dot { m } + \dot { k } l ( l - 1 ) } { 2 }\) will be the size and \(d _ { 1 } = \delta _ { \Lambda } \leq d _ { 2 } \leq d _ { 3 } \leq \ldots \leq \Delta _ { \Lambda } + ( l - 1 )\) be its degree sequence.

3.1. Transformations of Graph.

Suppose \(H ( \Lambda ) \subset E ( \Lambda )\) , the \(\Lambda ^ { ' } = \Lambda - H\) becomes the other graph developed by eliminating edge set \(H ( \Lambda )\) and \(\Lambda ^ { \prime \prime } = \Lambda - V _ { 1 } ( \Lambda )\) becomes new graph constructed by deleting vertex set \(V _ { 1 } ( \Lambda ) \subset V ( \Lambda )\). We will use the next coming transformations like those used in [32]. These transformations have solid efects on IDI of \(\Lambda _ { n , m } ^ { k , l }\)

Proposition 3.1. The IDI of some known graphs are,

1. If \(Λ\)is a complete graph of order r and size \(s = \frac { r ( r - 1 ) } { 2 }\) then \({ \frac { r } { \left( r - 1 \right) } } = { \frac { 2 s } { ( r - 1 ) ^ { 2 } } }\)
2. Consider \(\Lambda _ { r }\) be star graph of order \(r + 1\) and size \(s = r\) then \(I D I ( \Lambda _ { r } ) = { \frac { r ^ { 2 } + 1 } { r } } = { \frac { s ^ { 2 } + 1 } { s } }\)
3. Let \(Λ\) be a path graph of order r and size \(s = r - 1\) then \(I D I ( \Lambda ) = \frac { r + 2 } { 2 } = s + 3\)
4. \(L e t W _ { r }\)denotes the wheel graph of order \(r + 1\) and size \(s = 2 r\) then \(I D I (\Lambda) = I D I (W _ {r}) = \frac {r ^ {2} + 3}{3 r} = \frac {s ^ {2} + 6}{3 s}\)
5. Let \(\Lambda _ { n , m } = P _ { n } \times P _ { m }\) is a grid graph of order \(r = n m\) and size \(s = ( 2 n m - n - m )\) then\(I D I (\Lambda_ {n, m}) = \frac {3 n m + 2 (n + m) + 4}{1 2}\)
6. For cylinder graph \({ \Lambda } _ { n , m } = C _ { n } \times P _ { m }\) of order \(r = n m\) and size \(s = n ( 2 m - 1 )\) then\(I D I (\Lambda_ {n, m}) = \frac {n (3 m + 2)}{1 2}.\)

Transformation A

Let Λ be any simple graph with order and size is n, m respectively. Let \(w _ { i } \in\)\(V ( \Lambda ) , d _ { w _ { i } } \geq 1\) for \(1 \leq i \leq k \leq n\) and complete graph at \(w _ { i }\) of the form,

\[(w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3},..., w _ {i} u _ {i} ^ {l - 1}), (u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3},..., u _ {i} ^ {1} u _ {i} ^ {l - 1}), (u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {2} u _ {i} ^ {l - 1}),..., (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1})\]

comprises \(\Lambda _ { n , m } ^ { k , l }\). Then

\[\begin{array}{l} A (\Lambda_ {n, m} ^ {k, l}) = \Lambda + \sum_ {j = 1} ^ {k} \{(w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3},..., w _ {i} u _ {i} ^ {l - 1}) + (u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3},..., u _ {i} ^ {1} u _ {i} ^ {l - 1}) \\ \qquad + (u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {2} u _ {i} ^ {l - 1}) +... + (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}) \} \end{array}\]

The order and size of graph \(A ( \Lambda _ { n , m } ^ { k , l } )\) are \(n + k ( l - 1 )\) and \(\frac { 2 m + k l ( l - 1 ) } { 2 }\), respectively. Figure 1 illustrates the Transformation A.

Figure 1.Transformation A

Transformation B

Let \(A ( \Lambda _ { n , m } ^ { k , l } )\) be a graph with k number of complete graphs of order \(l ~ ( l \geq 3 )\). Let \(w _ { i } \in V ( \Lambda _ { n , m } ^ { k , l } )\) ) and form of \(w _ { i }\) is,

\[(w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3}, \dots , w _ {i} u _ {i} ^ {l - 1}), (u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3}, \dots , u _ {i} ^ {1} u _ {i} ^ {l - 1}), (u _ {i} ^ {2} u _ {i} ^ {3}, \dots , u _ {i} ^ {2} u _ {i} ^ {l - 1}), \dots , (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1})\]

In transformation B complete graph will be changed into Star graph and form of w will becomes,

\[\{w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3}, \dots , w _ {i} u _ {i} ^ {l - 1} \}\]

And

\[(\Lambda_ {n, m} ^ {k, l}) = A (\Lambda_ {n, m} ^ {k, l}) - \sum_ {j = 1} ^ {k} \{(u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3},..., u _ {i} ^ {1} u _ {i} ^ {l - 1}) + (u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {2} u _ {i} ^ {l - 1}) +... + (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}) \}\]

The order and size of graph \(B ( \Lambda _ { n , m } ^ { k , l } )\) are \(\frac { 2 n + k l ( l - 1 ) } { 2 }\) and \(\frac { 2 m + k l ( l - 1 ) } { 2 }\), respectively. Transformation B depicted in Figure 2.

If you want to cite or refer to your definition, lemma, proposition, or theorem later in the text, write it down using the following.

Figure 2.Transformation B

Theorem 3.2. Let \(Λ\) be the simple graph of order n and size m. Let \(\Delta\) and δ be its maximum and minimum degrees, respectively. And \(A ( \Lambda _ { n , m } ^ { k , l } )\) be the graph having k number of complete graphs attached to the fully connected vertices. Then

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} \leq I D I \{B (\Lambda_ {n, m} ^ {k, l}) \}\]

Proof. The transformation A transforms Λ into \(\Lambda _ { n , m } ^ { k , l }\) be a graph having k number of complete graphs of order \(l \ ( l \geq 3 )\). Then the construction of \(A ( \Lambda _ { n , m } ^ { k , l } ) ~ ( l \geq 3 )\) proposes

\[| O \{A (\Lambda_ {n, m} ^ {k, l}) \} | = n + k (l - 1) \mathrm{and} | E \{A (\Lambda_ {n, m} ^ {k, l}) \} | = \frac {2 m + k l (l - 1)}{2}\]

.

In transformation \(A ( \Lambda _ { n , m } ^ { k , l } )\) the number of vertices having degree \(d _ { v }\), k and \(k ( l - 1 )\) are \(( n - k ) , ( d _ { v } + l - 1 )\) and (l − 1), respectively. By applying the definition of IDI on \(A ( \Lambda _ { n , m } ^ { k , l } )\) we get,

\(IDI\{A(\Lambda_{n,m}^{k,l})\}=\sum_{v\in A(\Lambda_{n,m}^{k,l}),\,v=1}^{\,n-k}\frac{1}{d_v}+\sum_{v\in A(\Lambda_{n,m}^{k,l}),\,v=1}^{\,k}\frac{1}{d_v+(l-1)}+k(l-1)\frac{1}{(l-1)}\)

\[IDI\{A(\Lambda_{n,m}^{k,l})\}=\frac{n-k}{d_v}+\frac{k}{d_v+(l-1)}+k\tag{1}\]

The transformation \(A ( \Lambda _ { n , m } ^ { k , l } )\) transformed into \(B ( \Lambda _ { n , m } ^ { k , l } )\) , be a graph having k number of star graphs attached to the fully connected vertices. Then the establishment of \(B ( \Lambda _ { n , m } ^ { k , l } )\) presnts,

\[| O \{B (\Lambda_ {n, m} ^ {k, l}) \} | = \frac {2 n + k l (l - 1)}{2} \mathrm{and} | E \{B (\Lambda_ {n, m} ^ {k, l}) \} | = \frac {2 m + k l (l - 1)}{2}\]

.

\(\mathrm { S o }\) , there exists k vertices of degree \(\left( d _ { v } + \frac { l ( l - 1 ) } { 2 } \right)\) , vertices with degree \(( n - k )\) are \(d _ { v }\) and \(\frac { k l ( l - 1 ) } { 2 }\) vertices having degree 1. We get \(I D I \{ B ( \Lambda _ { n , m } ^ { k , l } ) \}\) as,

\[I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} = \sum_ {v \in B (\Lambda_ {n, m} ^ {k, l}), v = 1} ^ {n - k} \frac {1}{d _ {v}} + \sum_ {v \in B (\Lambda_ {n, m} ^ {k, l}), v = 1} ^ {k} \frac {1}{d _ {v} + \frac {l (l - 1)}{2}} + \frac {k l (l - 1)}{2}\]

\[I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {2 k}{2 d _ {v} + l (l - 1)} + \frac {k l (l - 1)}{2}\tag{2}\]

From Equations (1) and (2), we get

\[\begin{array}{c} I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {k}{d _ {v} + (l - 1)} + k - \frac {(n - k)}{d _ {v}} \\ - \frac {2 k}{2 d _ {v} + l (l - 1)} - \frac {k l (l - 1)}{2} \end{array}\]

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} = k \left[ \frac {1}{d _ {v} + (l - 1)} - \frac {l (l - 1)}{2} - \frac {2}{2 d _ {v} + l (l - 1)} + 1 \right] \tag {3}\]

Replace \(d _ { v }\) with maximum degree ∆ to minimize the Equation (3) which implies,

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} = k \biggl [ \frac {1}{\Delta_ {\Lambda} + (l - 1)} - \frac {l (l - 1)}{2} - \frac {2}{2 \Delta_ {\Lambda} + l (l - 1)} + 1 \biggr ] \leq 0\tag{4}\]

It is clear from Equation (4) that,

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} \leq 0 \text { which implies } I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} \leq I D I \{B (\Lambda_ {n, m} ^ {k, l}) \}\]

Figure 3 and Figure 4 are helpful in checking result derived in throughout the paper.

Example 3.3.Let \(\Lambda = C _ { 6 }\) be a cycle graph. The order and size of this graph are \(n = m = 6\) with the smallest and the largest degrees being \(\delta = \Delta = 2\). Take two copies \(k = 2\) of the complete graph of order \(l = 4\). After applying transformation A to \(\Lambda = C _ { 6 }\) , we obtain 6 vertices of degree 3, 2 vertices of degree 5, and 4 vertices \(o f\) degree 2. Therefore, \(\vert O \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} \vert ^ { - } = \vert O \{ A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} \vert = n + k ( l - 1 ) = 6 + 2 ( 3 ) = 12\) and \(| E \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | = | E \{ A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = \frac { 2 m + k l ( l - 1 ) } { 2 } = \frac { 2 ( 6 ) + 2 ( 4 ) ( 3 ) } { 2 } = 1 8\) Now \(I D I \{ { A ( \Lambda _ { n , m } ^ { k , l } ) } \} = I D I \{ { A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) } \} = 6 \left( \frac { 1 } { 3 } \right) + 2 \left( \frac { 1 } { 5 } \right) + 4 \left( \frac { 1 } { 2 } \right) = 4 . 4\). In transformation B, the complete graph is converted into a star graph. Thus, we obtain 2 vertices of degree 8, 4 vertices of degree 2, and 12 vertices of degree 1. Hence, for transformation B we have, \(| O \{ B ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ B ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = \frac { 2 n + k l ( l - 1 ) } { \mathfrak { d } } = \frac { 2 ( 6 ) + 2 ( 4 ) ( 3 ) } { 2 } = 1 8\) and \(| E \{ B ( \Lambda _ { n , m } ^ { k , l } ) \} | = | E \{ B ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = \frac { 2 m + k l ( l - 1 ) } { 2 } = \frac { 2 ( 6 ) + 2 ( 4 ) ( 3 ) } { 2 } = 18\).

Figure 3.Transformation A, B, C and D for C6

And IDI for transformation B is, IDI \(\{ B ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ B ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} = 2 \left( \frac { 1 } { 8 } \right) + 4 \left( { \frac { 1 } { 2 } } \right) + 1 2 = 1 4 . 2 5\). It is easy to verify that \(I D I \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} \le I D I \{ B ( \Lambda _ { n , m } ^ { k , l } ) \}\) The result obtained from Theorem 3.2, is given as

\[\begin{array}{l} I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} = k \left[ \frac {1}{\Delta \Lambda + (l - 1)} - \frac {l (l - 1)}{2} - \frac {2}{2 \Delta \Lambda + l (l - 1)} + 1 \right] \\ = 2 \left[ \frac {1}{2 + (4 - 1)} - \frac {4 (4 - 1)}{2} - \frac {2}{2 \times 2 + 4 (4 - 1)} + 1 \right] = - 9. 8 5 \leq 0 \end{array}\]

which is consistent with the aforementioned computations. For further details, see Figure 3. For further details, see Figure 3.

Example 3.4. Let \(\Lambda = P _ { 5 }\) be a path graph containing \(n = 5 , m = 4\) vertices and edges, respectively. In \(\Lambda = P _ { 5 }\) minimum degree is \(\delta = 1\) and maximum degree \(\Delta =\) 2. Consider \(k = 3\) and

\(l = 5 . ~ S o \left| { O \{ { A ( \Lambda _ { n , m } ^ { k , l } ) } \} } \right| = \left| { O \{ { A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) } \} } \right| = n + k ( l - 1 ) = 5 + 3 ( 4 ) = 1 7 \ a n d \ | { \cal E } \{ { \cal A } ( \Lambda _ { n , m } ^ { k , l } ) \} | = | { \cal E } \{ { \cal A } ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = \frac { 2 m + k l ( l - 1 ) } { 2 } = \frac { 2 ( 4 ) + 3 ( 5 ) ( 4 ) } { 2 } = 34\)

Figure 4.Transformation A, B, C and D for P5

Now IDI \([ A ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} = 1 2 \left( \frac { 1 } { 4 } \right) + 3 \left( \frac { 1 } { 6 } \right) + 2 = 5 . 5\). For trans-formation B, \(| O \{ B ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ B ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = \frac { \dot { 2 n } + k l ( l - 1 ) } { \mathfrak { d } } = \frac { 2 ( 5 ) + 3 ( 5 ) ( 4 ) } { \mathfrak { d } }\) 35 and \(\begin{array} { l } { | E \{ B ( { \Lambda } _ { n , m } ^ { k , l } ) \} | = | E \{ B ( { \Lambda } _ { 5 , 4 } ^ { 3 , 5 } ) \} | = \frac { 2 m + k l ( l - 1 ) } 2 = \frac { 2 ( 4 ) + 3 ( 5 ) ( 4 ) } 2 = 3 4 } \end{array}\). IDI for transformation B is,

\(I D I \{ B ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ B ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} = 3 \left( \frac { 1 } { 1 2 } \right) + 3 2 = 3 2 . 2 5\). One can verified very easily that \(I D I \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} \le I D I \{ B ( \Lambda _ { n , m } ^ { k , l } ) \}\). On the other hand result from Theorem (3.2) \(\ i s \ - 2 6 . 8 7 5 \leq 0\) also satisfied.

Transformation C

Let \(A ( \Lambda _ { n , m } ^ { k , l } )\) be a graph with k number of complete graphs of order \(l ~ ( l \geq 3 )\). Let \(w _ { i } \in V ( \Lambda _ { n , m } ^ { k , l } )\) and form of \(w _ { i }\) is,

\[\{(w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3}, \dots , w _ {i} u _ {i} ^ {l - 1}), (u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3}, \dots , u _ {i} ^ {1} u _ {i} ^ {l - 1}), (u _ {i} ^ {2} u _ {i} ^ {3}, \dots , u _ {i} ^ {2} u _ {i} ^ {l - 1}) , \dots , (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}) \}\]

In transformation C complete graph will be replaced with Cycle graph and form of \(w _ { i }\) will becomes,

\[\{w _ {i} u _ {i} ^ {1}, u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {2} u _ {i} ^ {3}, \dots , u _ {i} ^ {l - 3} u _ {i} ^ {l - 2}, u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}, u _ {i} ^ {l - 1} w _ {i} \}\]

And

\[\begin{array}{l} C (\Lambda_ {n, m} ^ {k, l}) = A (\Lambda_ {n, m} ^ {k, l}) + \sum_ {j = 1} ^ {k} \{w _ {i} u _ {i} ^ {1}, u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {l - 3} u _ {i} ^ {l - 2}, u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}, u _ {i} ^ {l - 1} w _ {i} \} \\ - \sum_ {j = 1} ^ {k} \{(u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3},..., u _ {i} ^ {1} u _ {i} ^ {l - 1}) + (w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3},..., w _ {i} u _ {i} ^ {l - 1}) + (u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {2} u _ {i} ^ {l - 1}) \\ +... + (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}) \} \end{array}\]

The cardinality of vertex and edge set of \(C ( \Lambda _ { n , m } ^ { k , l } )\) is \(n + k ( l - 1 )\) and \(m + k l\) 2 respectively.

Figure 5 presents the Transformation C

Figure 5.Transformation C.

Theorem 3.5. Let n, m be order and size of simple graph Λ, respectively. Let ∆ and δ be its maximum and minimum degrees. And \(A ( \bar { \Lambda } _ { n , m } ^ { k , l } )\) be the graph having k number of complete graphs attached to the fully connected vertices. Then

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} \leq I D I \{C (\Lambda_ {n, m} ^ {k, l}) \}\]

Proof. We start the proof from Equation (1) presented below

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {k}{d _ {v} + (l - 1)} + k\]

The transformation \(A ( \Lambda _ { n , m } ^ { k , l } )\) transformed into \(C ( \Lambda _ { n , m } ^ { k , l } )\) be a graph having k number of cycle graphs attached to the fully connected vertices. Then the setting up of \(C ( \dot { \Lambda _ { n , m } ^ { k , l } } )\) provides,

\[\left| O \{C (\Lambda_ {n, m} ^ {k, l}) \} \right| = n + k (l - 1) \text { and } \left| E \{C (\Lambda_ {n, m} ^ {k, l}) \} \right| = m + k l\]

.

The transformation \(C ( \Lambda _ { n , m } ^ { k , l } )\) exactly contained \(( n - k )\) vertices of degree \(d _ { v } , \ k\) vertices of degree \(( d _ { v } + 2 )\) and vertices with degree 2 are \(k ( l - 1 )\). By definition of ID index,

\[I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} = \sum_ {v \in C (\Lambda_ {n, m} ^ {k, l}), v = 1} ^ {n - k} \frac {1}{d _ {v}} + \sum_ {v \in C (\Lambda_ {n, m} ^ {k, l}), v = 1} ^ {k} \frac {1}{d _ {v} + 2} + k (l - 1) \frac {1}{2}\]

\[I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {k}{d _ {v} + 2} + \frac {k (l - 1)}{2}\tag{5}\]

Subtracting Equation (5) from Equation (1) we have,

\[\begin{array}{c} I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {k}{d _ {v} + (l - 1)} + k - \frac {(n - k)}{d _ {v}} - \frac {k}{d _ {v} + 2} \\ - \frac {k (l - 1)}{2} \end{array}\]

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} = k \left[ \frac {1}{d _ {v} + (l - 1)} - \frac {1}{d _ {v} + 2} - \frac {(l - 1)}{2} + 1 \right]\tag{6}\]

Return to \(d _ { v }\) as maximum degree \(\Delta\) to minimize the relation in Equation (6),

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} = k \left[ \frac {1}{\Delta_ {\Lambda} + (l - 1)} - \frac {1}{\Delta_ {\Lambda} + 2} - \frac {(l - 1)}{2} + 1 \right] \leq 0\tag{7}\]

Clearly, from Equation (7), we observe

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} \leq 0 \text { which implies } I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} \leq I D I \{C (\Lambda_ {n, m} ^ {k, l}) \}\]

Example 3.6.Let \(\Lambda = C _ { 6 }\) be a cycle graph. Here is \(n = 6\)\(m = 6\) and \(\delta =\)\(\Delta \ = \ 2\). Consider \(k = 2\) and \(l = 4\). Clearly \(| O \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | ~ = ~ | O \{ A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | ~ = n + k ( l - 1 ) = 6 + 2 ( 3 ) = 1 2\) and \(| E \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | = | E \{ A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = \frac { 2 m + k l ( l - 1 ) } { 9 } = { \frac { 2 ( 6 ) + 2 ( 4 ) ( 3 ) } { 2 } } = 1 8\). Now \(I D I \{ { A ( \Lambda _ { n , m } ^ { k , l } ) } \} = I D I \{ { A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) } \} = 6 \left( \frac { 1 } { 3 } \right) ^ { - } 2 \left( \frac { 1 } { 5 } \right) + 4 \left( { \frac { 1 } { 2 } } \right) = 4 . 4\). For transformation \(C , | O \{ C ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ C ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = n + k ( l - 1 ) = 6 + 2 ( 3 ) = 1 2\) and \(| E \{ C ( \Lambda _ { n , m } ^ { k , l } ) \} | = | E \{ C ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = m + k l = 6 + 2 ( 4 ) = 1 4\). And IDI for transformation C is, \(I D I \{ C ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ C ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} = 1 0 \left( \frac { 1 } { 2 } \right) + 2 \left( \frac { 1 } { 4 } \right) = 5.5\). It is easy to verify that \(I D I \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} \le I D I \{ C ( \Lambda _ { n , m } ^ { k , l } ) \}\). Whereas the result obtained from Theorem (3.5) is \(- 1 . 1 \leq 0\) also satisfied. For further information, see Figure 3.

Example 3.7.Let \(\Lambda = P _ { 5 }\) be a path graph containing \(n = 5 , m = 4\) vertices and edges, respectively. In \(\Lambda = P _ { 5 }\) minimum degree is \(\delta = 1\) and maximum degree \(\Delta \ = \ 2\) . Consider \(k = 3\) and \(l = 5\). So \(| \bar { O } \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = n + k ( l - 1 ) = 5 + 3 ( 4 ) = 1 7\) and \(| E \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | = | E \{ A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = \frac { 2 m + k l ( l - 1 ) } { 9 } = { \frac { 2 ( 4 ) + 3 ( 5 ) ( 4 ) } { 2 } } = 3 4\). Now \(I D I \{ { A ( \Lambda _ { n , m } ^ { k , l } ) } \} = I D I \{ { A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) } \} = 1 2 \left( { \frac { 1 } { 4 } } \right) ^ { \frac { c } { + } } 3 \left( { \frac { 1 } { 6 } } \right) + 2 = 5 . 5\). For transformation \(\mathcal { O } , | O \{ C ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ C ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = n + k ( l - 1 ) = 5 + 3 ( 4 ) = 1 7\) and \(| E \{ C ( \Lambda _ { n , m } ^ { k , l } ) \} | = | E \{ C ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = m + k l = 4 + 3 ( 5 ) = 1 9\). The IDI for transformation \({ \textit { C i s } } ,\)\(I D I \{ C ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ C ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} = 3 \left( \frac { 1 } { 4 } \right) + 2 + 6 = 8 . 7 5\). One can verified very easily that \(I D I \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} \le I D I \{ C ( \Lambda _ { n , m } ^ { k , l } ) \}\). On the other hand result from Theorem (3.5) is \(- 3 . 3 7 5 \leq 0\) also satisfied. For detailed information, see Figure 4.

Transformation D

Let \(A ( \Lambda _ { n , m } ^ { k , l } )\) be a graph with k number of complete graphs of order \(l ~ ( l \geq 3 )\). Let \(w _ { i } \in V ( \Lambda _ { n , m } ^ { k , l } )\) ) and form of \(w _ { i }\) is,

\[\begin{array}{l} \{(w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3},..., w _ {i} u _ {i} ^ {l - 1}), (u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3},..., u _ {i} ^ {1} u _ {i} ^ {l - 1}), (u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {2} u _ {i} ^ {l - 1}) \\ ,..., (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}) \} \end{array}\]

In transformation D complete graph will be converted into Path graph and form of \(w _ { i }\) will becomes, \(\{ w _ { i } u _ { i } ^ { 1 } , u _ { i } ^ { 1 } u _ { i } ^ { 2 } , u _ { i } ^ { 2 } u _ { i } ^ { 3 } , . . . , u _ { i } ^ { l - 3 } u _ { i } ^ { l - 2 } , u _ { i } ^ { l - 2 } u _ { i } ^ { l - 1 } \}\). We have,

\[\begin{array}{l} D (\Lambda_ {n, m} ^ {k, l}) = A (\Lambda_ {n, m} ^ {k, l}) + \sum_ {j = 1} ^ {k} \{w _ {i} u _ {i} ^ {1}, u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {l - 3} u _ {i} ^ {l - 2}, u _ {i} ^ {l - 2} u _ {i} ^ {l - 1} \} \\ \qquad - \sum_ {j = 1} ^ {k} \{(w _ {i} u _ {i} ^ {1}, w _ {i} u _ {i} ^ {2}, w _ {i} u _ {i} ^ {3},..., w _ {i} u _ {i} ^ {l - 1}) + (u _ {i} ^ {1} u _ {i} ^ {2}, u _ {i} ^ {1} u _ {i} ^ {3},..., u _ {i} ^ {1} u _ {i} ^ {l - 1}) \\ \qquad + (u _ {i} ^ {2} u _ {i} ^ {3},..., u _ {i} ^ {2} u _ {i} ^ {l - 1}) +... + (u _ {i} ^ {l - 2} u _ {i} ^ {l - 1}) \} \end{array}\]

.

The set of vertex transformations D has cardinality \(\frac { 2 n + k l ( l - 1 ) } { 2 }\) and size of D \(\mathrm { i s } \ \frac { 2 m + k l ( l - 1 ) } { 2 }\), respectively.

Transformation D is described in Figure 6.

Theorem 3.8. Let \(Λ\) be the simple graph on n vertices and m edges. Let \(\Delta\) and δ be its maximum and minimum degrees, respectively. And \(A ( \Lambda _ { n , m } ^ { k , l } )\) be the graph that has k number of complete graphs attached to the fully connected vertices. Then

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} \leq I D I \{D (\Lambda_ {n, m} ^ {k, l}) \}\]

Proof. Again, starting from Equation (1) as restated here,

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {k}{d _ {v} + (l - 1)} + k\tag{8}\]

The transformation \(A ( \Lambda _ { n , m } ^ { k , l } )\) transformed into \(D ( \Lambda _ { n , m } ^ { k , l } )\) be a graph having k number of path graphs attached to the vertices. Then a lay out of \(D ( \Lambda _ { n , m } ^ { k , l } )\) produces,

\[| O \{D (\Lambda_ {n, m} ^ {k, l}) \} | = \frac {2 n + k l (l - 1)}{2}\]

and \(| E \{D (\Lambda_ {n, m} ^ {k, l}) \} | = \frac {2 m + k l (l - 1)}{2}\).

The transformation \(D ( \Lambda _ { n , m } ^ { k , l } )\) consists of \(( n - k )\) and k vertices of degrees \(d _ { v }\) and \(d _ { v } + 1\), respectively. There exist at least k vertices of degree 1 and number of vertices having degree 2 are \(k \left( \frac { l ( l - 1 ) } { 2 } - 1 \right)\). We have,

\[I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} = \sum_ {v \in C (\Lambda_ {n, m} ^ {k, l}), v = 1} ^ {n - k} \frac {1}{d _ {v}} + \sum_ {v \in C (\Lambda_ {n, m} ^ {k, l}), v = 1} ^ {k} \frac {1}{d _ {v} + 1} + k \left(\frac {\frac {l (l - 1)}{2} - 1}{2}\right) + k\]

\[I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {k}{d _ {v} + 1} + k \left(\frac {l (l - 1) - 2}{4}\right) + k\tag{9}\]

Solving Equations (8) and (9) simultaneously, we get

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} = \frac {(n - k)}{d _ {v}} + \frac {k}{d _ {v} + (l - 1)} + k - \frac {(n - k)}{d _ {v}} - \frac {k}{d _ {v} + 1} - k \left(\frac {l (l - 1) - 2}{4}\right) - k\]

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} = k \bigg [ \frac {1}{d _ {v} + (l - 1)} - \frac {1}{d _ {v} + 1} - \frac {l (l - 1) - 2}{4} \bigg ]\tag{10}\]

Put back \(d _ { v }\) with maximum degree \(\Delta\) Equation (10) to get the required result,

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} = k \left[ \frac {1}{\Delta_ {\Lambda} + (l - 1)} - \frac {1}{\Delta_ {\Lambda} + 1} - \frac {l (l - 1) - 2}{4} \right] \leq 0\tag{11}\]

From Equation (11), We get

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} \leq 0\]

which implies

\[I D I \{A (\Lambda_ {n, m} ^ {k, l}) \} \leq I D I \{D (\Lambda_ {n, m} ^ {k, l}) \}\]

.

Example 3.9.Let \(\Lambda ~ = ~ C _ { 6 }\) be a cycle graph. Here is \(n ~ = ~ 6 , ~ m ~ = ~ 6\) and \(\delta = \Delta = 2\). Consider \(k = 2\) and \(l = 4\). Clearly \(| O \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = n+k(l-1)=6+2(3)=12\) and \(|E\{A(\Lambda_{n,m}^{k,l})\}|=|E\{A(\Lambda_{6,6}^{2,4})\}|=\frac{2m+kl(l-1)}{2}= { \frac { 2 ( 6 ) + 2 ( 4 ) ( 3 ) } { 2 } } = 1 8\). Now \(I D I \{ { A ( \Lambda _ { n , m } ^ { k , l } ) } \} = I D I \{ { A ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) } \} = 6 \left( \frac { 1 } { 3 } \right) + 2 \left( \frac { 1 } { 5 } \right) + 4 \left( { \frac { 1 } { 2 } } \right) = 4 . 4\). For transformation D, \(| O \{ D ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ D ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | = \frac { 2 n + k l ( l - 1 ) } { 2 } = \frac { 2 ( 6 ) + 2 ( 4 ) ( 3 ) } { 2 } = 1 8\) and \(| E \{ D ( \Lambda _ { n , m } ^ { k , l } ) \} | ~ = ~ | E \{ D ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} | ~ = ~ \frac { 2 m + k l ( l - 1 ) } { 2 } ~ = \frac { 2 ( 6 ) + 2 ( 4 ) ( 3 ) } { 2 } = 1 8\). And IDI for transformation D is, \(I D I \{ D ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ D ( \Lambda _ { 6 , 6 } ^ { 2 , 4 } ) \} = 1 4 \left( \frac { 1 } { 2 } \right) ^ { \omega } + 2 \left( \frac { 1 } { 3 } \right) + 2 = 9 . 6\). It is easy to verify that \(I D I \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} \le I D I \{ D ( \Lambda _ { n , m } ^ { k , l } ) \}\). Where as the result obtained from Theorem (3.8) \({ i s \mathrm { ~ - } 5 . 2 \leq 0 }\) also satisfied.

For further information, see Figure 3.

Figure 6.Transformation D

Example 3.10. Let \(\Lambda = P _ { 5 }\) be a path graph containing \(n = 5 , m = 4\) vertices and edges, respectively. In \(\Lambda = P _ { 5 }\) minimum degree is \(\delta = 1\) and maximum degree \(\Delta = 2\). Consider \(k = 3\) and \(l = 5\). So \(| O \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = n + k ( l - 1 ) = 5 + 3 ( 4 ) = 1 7\) and \(| E \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} | = | E \{ A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = \frac { 2 m + k l ( l - 1 ) } { 2 } = \frac { 2 ( 4 ) + 3 ( 5 ) ( 4 ) } { 2 } = 34\).

Now \(I D I \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ A ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} = 1 2 \left( \frac { 1 } { 4 } \right) + 3 \left( \frac { 1 } { 6 } \right) + 2 = 5 . 5\). For transformation \(D , | O \{ D ( \Lambda _ { n , m } ^ { k , l } ) \} | = | O \{ D ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} | = \frac { \dot { 2 n } + k l ( l { - } { 1 } ) } { 2 } = \frac { 2 ( 5 ) + 3 ( 5 ) ( 4 ) } { 2 } = 35\) and \(|E\{D(\Lambda_{n,m}^{k,l})\}|=|E\{D(\Lambda_{5,4}^{3,5})\}|=\frac{2m+kl(l-1)}{2}=\frac{2(4)+3(5)(4)}{2}=34.\) The IDI for transformation D is, \(I D I \{ D ( \Lambda _ { n , m } ^ { k , l } ) \} = I D I \{ D ( \Lambda _ { 5 , 4 } ^ { 3 , 5 } ) \} = 2 7 \left( \frac { 1 } { 2 } \right) + 3 \left( { \frac { 1 } { 3 } } \right) + 5 \left( { \frac { 1 } { 2 } } \right) = 1 7\). One can verified very easily that \(I D I \{ A ( \Lambda _ { n , m } ^ { k , l } ) \} \le I D I \{ D ( \Lambda _ { n , m } ^ { k , l } ) \}\) On the other hand result from Theorem (3.8) \(\ i s \ - 1 4 . 1 2 5 \leq 0\) also satisfied.

Corollary 3.11.Let Λ be the simple graph on n vertices and m edges and \(A ( \Lambda _ { n , m } ^ { k , l } ) , B ( \Lambda _ { n , m } ^ { k , l } ) , C ( \Lambda _ { n , m } ^ { k , l } ) ,\) and \(D ( \Lambda _ { n , m } ^ { k , l } )\) are transformed graphs.Then

\[\begin{array}{l} I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} \geq I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} \\ I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} \geq I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} \end{array}\]

Proof. Subtracting Equation (5) from Equation (2) we have,

\[I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{C (\Lambda_ {n, m} ^ {k, l}) \} = k \left[ \frac {2}{2 d _ {v} + l (l - 1)} + \frac {l (l - 1)}{2} - \frac {1}{d _ {v} + 2} - \frac {(l - 1)}{2} \right]\tag{12}\]

Replace \(d _ { v }\) with maximum degree \(\Delta\) we get,

\[I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} \geq I D I \{C (\Lambda_ {n, m} ^ {k, l}) \}\]

.

Solving Equations (2) and (9) simultaneously,

\[\begin{array}{c} I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} - I D I \{D (\Lambda_ {n, m} ^ {k, l}) \} = k \bigg [ \frac {2}{2 d _ {v} + l (l - 1)} + \frac {l (l - 1)}{2} - \frac {1}{d _ {v} + 1} \\ - (\frac {l (l - 1) - 2}{4}) - 1 \bigg ] \end{array}\tag{13}\]

By replacing \(d _ { v }\) with \(\Delta\) we get the required result,

\[I D I \{B (\Lambda_ {n, m} ^ {k, l}) \} \geq I D I \{D (\Lambda_ {n, m} ^ {k, l}) \}.\]

4. CONCLUDING REMARKS

The analysis of mathematical aspects involving topological indices is a partly open issue that “for which member from a family of graphs, a particular index, has extremal value?” In this paper, we probed the impact of IDI that drew attention through myriad conjectures produced by the software Grafiti concerning four new graph transformations. These transformations enable us to create new molecular structures, and IDI, being a good predictor of certain properties of octane isomers, can be used to study those properties for new complicated molecules. We provided a relation among IDI for four graph transformations namely A, B, C, and D. In particular, we concluded that the value of IDI remains lesser for transformation A as compared to transformations B, C, and D. Moreover, the value of IDI for transformation B will remain greater than both transformations C and D. Furthermore, result established are tested and evaluated on specific examples to check their accuracy. The analysis IDI indicates that graph A exhibits a higher structural contribution, branching, complexity, and connectivity compared to its transformations B, C, and D, while among the transformed graphs, B consistently maintains a greater IDI than both C and D. This ordering highlights the efect of diferent graph transformations on structural properties captured by the IDI and can guide the identification of extremal or structurally significant graphs.

Competing Interests

The authors declare no conflict of interest.

References

1. Bondy J.A., Murty U.S.R.. Graph theory with applications. 1976; 290Publisher Full Text
2. Todeschini R., Consonni V.. John Wiley & Sons; 2008. Publisher Full Text
3. Gutman I., Polansky O.E.. Springer Science & Business Media; 2012. Publisher Full Text
4. Wu B., Meng J.-x. Basic properties of total transformation graphs. J. Math. Study. 2001; 34(2)
5. De N., Pal A., Nayeem S.M.A.. The irregularity of some composite graphs. International Journal of Applied and Computational Mathematics. 2016; 2(3)DOI
6. Das K.C., Gutman I.. Some properties of the second zagreb index. MATCH Commun. Math. Comput. Chem. 2004; 52(1)Publisher Full Text
7. Akhter S., Imran M.. On molecular topological properties of benzenoid structures. Canadian Journal of Chemistry. 2016; 94(8)DOI
8. Imran M., Iqbal M.A., Liu Y., Baig A.Q., Khalid W., Zaighum M.A.. Computing eccentricity-based topological indices of 2-power interconnection networks. Journal of Chemistry. 2020; 1DOI
9. Wiener H.. Structural determination of parafin boiling points. Journal of the American chemical society. 1947; 69(1)DOI
10. New concepts II. Springer; 2005. Publisher Full Text
11. On vertexdegree-based molecular structure descriptors. 2011. Publisher Full Text
12. Gutman I., Polansky O.E.. Springer Science & Business Media; 2012. Publisher Full Text
13. Xu K., Das K.C.. Trees, unicyclic, and bicyclic graphs extremal with respect to multiplicative sum zagreb index. Match-Communications in Mathematical and Computer Chemistry. 2012; 68(1)Publisher Full Text
14. Das K.C., Gutman I.. Some properties of the second zagreb index. MATCH Commun. Math. Comput. Chem. 2004; 52(1)Publisher Full Text
15. Furtula B., Gutman I., Dehmer M.. On structure-sensitivity of degree-based topological indices. Applied Mathematics and Computation. 2013; 219(17)DOI
16. Gutman I., Das K.C.. The first zagreb index 30 years after. MATCH Commun. Math. Comput. Chem. 2004; 50(1)DOI
17. Li X., Zhao H.. Trees with the first three smallest and largest generalized topological indices. MATCH Commun. Math. Comput. Chem. 2004; 50Publisher Full Text
18. Li X., Zheng J.. A unified approach to the extremal trees for diferent indices. MATCH Communications in Mathematical and in Computer Chemistry. 2005; 54(1)Publisher Full Text
19. Zhang Z., Zhang J., Lu X.. The relation of matching with inverse degree of a graph. Discrete Mathematics. 2005; 301(2–3)DOI
20. Fajtlowicz S.. On conjectures of grafiti-ii. Congressus Numerantium. 1987; 60Publisher Full Text
21. Fajtlowicz S.. Annals of Discrete Mathematics. Elsevier; 1988. DOI
22. Mukwembi S.. On diameter and inverse degree of a graph. Discrete Mathematics. 2010; 310(4)DOI
23. Chen X.G., Fujita S.. On diameter and inverse degree of chemical graphs. Applicable Analysis and Discrete Mathematics. 2013; 7(1)Publisher Full Text
24. Das K.C., Xu K., Wang J.. On inverse degree and topological indices of graphs. Filomat. 2016; 30(8)DOI
25. Xu K., Das K.C.. Some extremal graphs with respect to inverse degree. Discrete Applied Mathematics. 2016; 203DOI
26. Das K.C., Balachandran S., Gutman I.. Inverse degree, randi ́c index and harmonic index of graphs. Applicable Analysis and Discrete Mathematics. 2017; 11(2)Publisher Full Text
27. Sampathkumar E., Chikkodimath S.. Semitotal graphs of a graph-i, j. Karnatak Univ. Sci. 1973; 18
28. Wang H., Liu J.-B., Wang S., Gao W., Akhter S., Imran M., Farahani M.R.. Sharp bounds for the general sum-connectivity indices of transformation graphs. Discrete Dynamics in Nature and Society. 2017; 1DOI
29. Mohanappriya G., Vijayalakshmi D.. Symmetric division degree index and inverse sum index of transformation graph. Journal of Physics: Conference Series. 2018; 1139DOI
30. On the inverse degree index and decompositions in graphs. Kuwait Journal of Science. 2019; 46(4)Publisher Full Text
31. Inequalities on the inverse degree index. Journal of Mathematical Chemistry. 2019; 57(5)DOI
32. Asif M., Hussain M., Almohamedh H., Alhamed K.M., Almotairi S.. An approach to the extremal inverse degree index for families of graphs with transformation efect. Journal of Chemistry. 2021; 1DOI
33. Manian M.A., Heidarian S., Haghani F.Khaksar. Maximum and minimum values of inverse degree and forgotten indices on the class of all unicyclic graphs. AKCE International Journal of Graphs and Combinatorics. 2023; 20(1)DOI
34. Inverse degree index: exponential extension and applications. Journal of Mathematical Chemistry. 2023; 61(5)DOI
35. Applications of the inverse degree index to molecular structures. Journal of Mathematical Chemistry. 2024; 62(1)DOI
36. New bounds for variable topological indices and applications. Journal of Mathematical Chemistry. 2024; 62(6)DOI
37. Irshad R., Ahmad M., Hussain M.. Efect of atom bond connectivity index on family of graphs under transformation. Hacettepe Journal of Mathematics and Statistics. 2025. DOI

Copyright & License

© 2026 Journal of the Indonesian Mathematical Society.

This work is licensed under a Creative Commons Attribution-NonCommercial-NoDerivatives 4.0 International License.
